Daher TBM 960 - Three View Drawing

1.2 -
Three View Drawing
Figure 1.2.1 - Three V
iew Drawing (1/2)
8.15 in
9.56 ft
(*)
(*)
12.71 ft
mini 0.207 m
2.914 m
3.874 m
4.355 m
14.29 ft
I4061000AAAHMA8000
10.736 m
35.22 ft
(*) Airplane on a level surface with fully extended FWD shock absorber
Section 1
General
Pilot's Information Manual
PIM TBM 960 - Edition 0
Rev. 00
Page 1.2.1
PIM - DO NOT USE FOR FLIGHT OPERATIONS
