Dimmable Windows, if installed
See Figure 7.3.12.
The airplane is equipped
with dimmable windows. Passengers can individually set
the opacity from 0% to 50% for visual comfort purpose through the control panel
located at the bottom of each dimmable window.
By touching the CABIN marking of a control panel, a passenger can set all the
dimmable windows simultaneously. After few seconds, the control panel turns off
and the control mode of all dimmable windows returns to individual control.
The dimmable windows are electrically supplied by the BUS 4 bar and protected
by the DIM WINDOWS breaker located on Frame C13bis.
When not powered, the dimmable windows are 50% shaded.
Figure 7.3.12 - Dimmable Windows Control
Seats, Belts and Harnesses
Heated Seats
See Figure 7.3.13.
Section 7
Description
Pilot's Information Manual
PIM TBM 960 - Edition 0
Rev. 01
Page 7.3.26
PIM - DO NOT USE FOR FLIGHT OPERATIONS
