Before Taxiing 2 / 3
► Continuing
Perform AP / TRIMS test.
8 - AP / TRIMS .................................................................................
Check
NOTE
Detailed control procedures of autopilot and electrical pitch trim are
described in the Garmin Integrated Flight Deck Pilot's Guide.
9 - Pitch trim .................................................................................. UP / DN
10 - Pitch trim
............................................................. Adjust in green range
Graduated from 12 to 37%
11 - Yaw trim ......................................................................................... L / R
12 - Yaw trim .............................................................. Adjust in green range
Takeoff range
13 - Roll trim ......................................................................................... L / R
14 - Roll trim .......................................................... Adjust at neutral position
15 - FLAPS lever .............................................................................................. UP
Perform MFD flight management
16 - Weight computing ............................................................... Set / Check
17 - FOB synchronization ........................................................................ Set
If requested:
18 - FPL ......................................................................................... Set
19 - LFE selection ...................................................................... Set / Check
Landing Field Elevation selection is done on the
touchscreen controller using either:
- an automatic entry of the destination airport
from the flight plan in the FMS, or
- a manual entry by pressing: HOME,
AIRCRAFT SYSTEMS, LFE and then MANUAL
20 - VHF / VOR / GPS .............................................................. Adjust / Test
Continue ►
Pilot's Information Manual
Section 4
Normal Procedures
PIM TBM 960 - Edition 0
Rev. 01
Page 4.4.33
PIM - DO NOT USE FOR FLIGHT OPERATIONS
