Daher TBM 960 - Page 566

Figure 6.3.1 - Baggage Limits
I4113500AAABMA8401
FWD
39
kg
(86 lbs)
61
kg
(134 lbs)
HEIGHT RE FER ENC E
HEIGHT REFER ENC E
FWD
SMALL NET
LARGE NET
100
kg
(220 lbs)
80
kg
(176 lbs)
165
(33.8 lbs/sq.ft)
kg/m2
188
kg/m2
80
kg
(176 lbs)
165
(33.8 lbs/sq.ft)
kg/m2
(38.5 lbs/sq.ft)
C11
C13 bis
C11
C14
C14
Authorized anchoring points are identified with green self-adhesive
labels affixed to the inside of the rail.
A placard indicates loading limits for each securing net.
The load within
the cargo zone should be evenly distributed, and
ensure that overall weight is centered.
When using the large net, distribute the weight in each zone,
delineated by the step up in the floor, according to the zone limits.
Section 6
Weight and Balance
Pilot's Information Manual
PIM TBM 960 - Edition 0
Rev. 00
Page 6.3.2
PIM - DO NOT USE FOR FLIGHT OPERATIONS
