Prohibited area
Authorized anchoring area
Authorized anchoring area
Prohibited area
I4113500AAABMA8000
- the large cargo net is attached through seven anchoring points on seat rails,
between Frame C11 and Frame C13bis and six anchoring points on fuselage
sides, at Frame C14 – see Figure 7.2.2.
NOTE
Original partition net must be disconnected from side walls and placed on
the floor.
Prohibited area
Authorized anchoring area
I4113500AAABMA8100
Authorized anchoring points are identified with green self-adhesive labels affixed
to the inside of the seat rail.
Section 7
Description
Pilot's Information Manual
PIM TBM 960 - Edition 0
Rev. 01
Page 7.3.43
