Figure 7.13.1 - Vacuum System
1
5
4
2
3
6
CAS window
VAC UUM LOW
Avionics
display
C4370000AAAAMA8000
To
atmosphere
Deicing
Powerplant
Firewall
C2
R
R
High pressure
Key
Vacuum
Controlled
Cabin
system
pressure
Section 7
Description
Pilot's Information Manual
PIM TBM 960 - Edition 0
Rev. 00
Page 7.13.3
