Daher TBM 960 - 6.4 - Determining the airplane weight and balance after the installation of the Extended large storage cabinet option

Pilot's Operating Handbook
Supplement 73
Extended large storage cabinet
Edition 0 - February 14, 2020
Rev. 0
Page 9.73.5
Using the weight and balance form
▲ CAUTION ▲
Use the em
pty weight, arm and CG % from the weight and balance
report that includes the Extended large storage cabinet option.
▲
Use the following load form to determine the weightand balance ofthe airplane.Refer
to procedure Utilization of weight and balance graph in section 6.4 of the standard
POH.
S/
R/
A/
O
Item
OPT70
or
MOD70
Required (R) or Standard (S) or Optional (A or O)
equipment
Weight
per unit
lb
(kg)
Arm
in.
(m)
25 - Equipment and furnishings
O 0684-25 Extended large storage cabinet
Version A : cabinet without electrical supply 35.519
(16.11)
214.53
(5.449)
Version B : cabinet with electrical supply 40.00
(18.16)
214.68
(5.453)
PIM - DO NOT USE FOR FLIGHT OPERATIONS
