Pilot's Operating Handbook
Supplement 73
Extended large storage cabinet
Edition 0 - February 14, 2020
Rev. 0
Page 9.73.12
The cabinetis electically supplied by the BUS 4 bar and is protected by the CABINET
breaker l
ocated on frame C13bis.
Circuit breakers are located under the roof of the aft large drawer (refer to A).
Figure 9.73.6 - Circuit breakers and plugs
List of circuit breakers located inside the cabinet :
BUS 4
USB USB plug protection
115 VAC INVERTER 115 VAC inverter protection
115 VAC PLUG 115 VAC plug protection
SECTION 8
Handling, servicing and maintenance
The information in this section supplements and/or replaces the information in
section 8 Handling, servicing and maintenance of the standard POH when the
airplane is equipped with the Extended large storage cabinet option.
Refer to the Maintenance Manual for the installation and removal of the cabinet.
Installation and removal of the cabinet must be performed in a service center.
