User's Manual
12
Figure 2-24 Remove screws
Step 2 Remove the cover.
Figure 2-25 Remove cover
Step 3 Align the screws of the HDD with the holes on the back of the device and fasten them.
Figure 2-26 Fasten screws
Step 4 Connect the HDD cable and the power cable to the mainboard.
