User's Manual
297
Figure 5-275 FTP
Step 2 Configure the settings for the FTP settings parameters.
Table 5-70 FTP settings parameters
Parameter Description
Enable Enable the FTP upload function.
FTP type
●
FTP: Plaintext transmission.
●
SFTP: Encrypted transmission (recommended)
Server Address IP address of FTP server.
Port
●
FTP: The default is 21.
●
SFTP: The default is 22.
Anonymous
Enter the username and password to log in to the FTP server.
Enable the anonymity function, and then you can login
anonymously without entering the username and password.
Username
Password
Storage Path
Create folder on FTP server.
●
If you do not enter the name of remote directory, system
automatically creates the folders according to the IP and
time.
●
If you enter the name of remote directory, the system
creates the folder with the entered name under the FTP
root directory first, and then automatically creates the
folders according to the IP and time.
To Next Page
