Local Configurations 91
5.4.4.3 Calling Patterns
On the Expanded PTZ Control Panel, in the No. box, enter the value of the pattern that
Step 1
you want to call.
Call to call the pattern. Step 2
The PTZ camera moves according to the configured pattern repeatedly.
Click again to stop calling the pattern. Step 3
5.4.4.4 Calling AutoScan
On the Expanded PTZ Control Panel, in the No. box, enter the value of the border that Step 1
you want to call.
Click . Step 2
The PTZ camera performs scanning according to the configured borders.
Click again to stop auto scanning. Step 3
5.4.4.5 Calling AutoPan
On the Expanded PTZ Control Panel, click to start moving in horizontal direction. Step 1
Click again to stop moving. Step 2
5.4.4.6 Using AUX Button
On the Expanded PTZ Control Panel, click , the AUX setting interface is displayed. See
Figure 5-59.
In the Direct Aux list, select the option that corresponds to the applied protocol.
In the Aux Num box, enter the number that corresponds to the AUX switch on the decoder.
Figure 5-59
5.4.5 Calling OSD Menu
For the coaxial camera, you can call the OSD menu through the Expanded PTZ Control Panel.
See Figure 5-58.
