Local Configurations 92
On the Expanded PTZ Control Panel, click . Step 1
The MENU OPERATION interface is displayed. See Figure 5-60.
Figure 5-60
Click Enter. Step 2
The OSD menu is displayed. See Figure 5-61.
Figure 5-61
On the MENU OPERATION interface, click the arrow button to select the onscreen Step 3
parameters.
Click Enter to complete the settings. Step 4
5.5 Configuring Camera Settings
5.5.1 Configuring Image Settings
You can configure the image settings such as saturation, contrast, brightness, sharpness for
each connected camera.
Select Main Menu > CAMERA > IMAGE. Step 1
The IMAGE interface is displayed. See Figure 5-62 for analog channel and Figure 5-63
for digital channel.
