Local Configurations 211
In the Connect Type list, select the connection protocol type.
Click , the IP Address interface is displayed.
In the Source IP box, enter the IP address (the machine that is
connected to the Device) that sends messages.
Select a character encoding mode.
In the Overlay list, Select Turn or ROLL.
When the network is not working correctly and cannot be
recovered after the entered timeout limit, the POS information will
not display normally. After the network is recovered, the latest
POS information will be displayed.
Enter the time that how long you want to keep the POS
information displaying. For example, enter 5, the POS information
disappear from the screen after 5 seconds.
In the Font Size list, select Small, Medium, or Big as the text
size of POS information
In the color bar, click to select the color for the text size of POS
information.
Enable the POS Info function, the POS information displays in the
live view screen.
Enter the transaction start character and end character.
Enter the line delimiter that you want to use.
Table 5-55
Click Apply to complete the settings. Step 3
5.15 Configuring Backup Settings
5.15.1 Finding USB Device
When you inset a USB storage device into the USB port of the Device, the Device detects the
USB storage device and pops up "Find USB device" interface, which provides you a shortcut to
perform backup and upgrading operations. See Figure 5-185.
For details, see "5.15.2 Backing up Files", "5.21.2 Viewing Log Information", "5.20.4 Exporting
and Importing System Settings", and "5.20.6 Upgrading the Device."
