Local Configurations 101
The CHANNEL TYPE interface is displayed. See Figure 5-68.
Figure 5-68
Configure the channels. Step 2
Analog Channel: Select the transmission medium such as CVI, CVBS, and then
follow the onscreen instructions to complete the settings.
IP Channel: The Device provides expanded IP channels for your use. For example,
the 17–24 channels in Figure 5-68 are expanded IP channels. To enable the IP
channel, select from the last channel number 17–24 check box. Then follow the
onscreen instructions to complete the settings.
The 17–24 channels are only for IP camera and the range changes dependent on
the model you purchased.
The channel selection for analog camera or IP camera are in sequence, for
example, if you want to select channels for IP camera, you need to select the 17–
24 check box first, and then you cannot jump to select the channel 15 directly until
you have selected the channel 16.
Click Apply and follow the onscreen instructions to complete the settings. Step 3
5.5.7 Upgrading Coaxial Camera
Select Main Menu > CAMERA > COAXIAL UPGRADE. Step 1
The COAXIAL UPGRADE interface is displayed. See Figure 5-69.
