Local Configurations 58
Figure 5-25
Configure the settings for the snapshot parameters. See Table 5-7. Step 2
In the Manual Snap list, select how many snapshots you want to take
each time.
In the Channel list, select the channel that you want to configure the
settings for.
In the Mode list, select type of snapshots.
In the Image Size list, select a value for the image.
Configure the image quality by 6 levels. The higher the level, the
better the image will become.
Configure or customize the snapshot frequency.
Table 5-7
5.1.4.8 Configuring Basic Storage Settings
You can configure the settings for the situations when HDD is full, file length and time length of
recorded video, and the settings if to auto-delete the old files.
You can also configure basic storage settings by selecting Main Menu > STORAGE > BASIC.
After you have configured the encode settings, on the SNAPSHOT interface, click Step 1
Next.
The BASIC interface is displayed. See Figure 5-26.
