Local Configurations 100
Figure 5-67
Configure the settings for the covered area parameters. See Table 5-27. Step 2
In the Channel list, select the channel that you want to configure the
settings for.
Preview: Select the Preview check box to apply the configured
covered block to the selected channel window in the live view
screen.
Record: Select the Record check box to apply the configured
covered block to the selected channel window during recording.
To configure covering block, do the following:
1. Select the Preview check box or the Record check box, or select
the both. The "1, 2, 3, 4" buttons are activated.
2. Click the buttons to select blocks.
3. A triangle solid black block is displayed. You can drag the block to
the area that you want to cover and adjust the size of the block.
4. You can configure total 4 covered blocks.
Table 5-27
Click Apply to complete the settings. Step 3
5.5.6 Configuring Channel Type
You can configure the channel type as Analog or IP channel.
Select Main Menu > CAMERA > CHANNEL TYPE. Step 1
