Dahua NVR52-4KS2 SERIES User Manual

NVR52-8P-I/L/NVR42-EI/NVR42-P-EI/NVR42-8P-EI/
NVR42-16P-EI
Background Information
Dierent models have dierent numbers of HDDs.
Procedure
Step 1 Remove the four xing screws on the rear panel.
Figure 3-12 Remove screws
Step 2 Remove the case cover along the direction shown in the following arrow.
Figure 3-13 Remove cover
Step 3 Match the four holes on the baseboard to place the HDD.
User's Manual
95
