PoE operation Description
PoE connection
mapping
●
The PoE ports are bound to corresponding channels. When an IPC is
connected to PoE port 1, the corresponding channel is Channel 1.
●
The PoE ports are not bound to correpondng channels. When an IPC is
connected to PoE port 5, the corresponding channel is the rst idle
channel among all channels.
5.11.18 P2P
P2P is a kind of convenient private network penetration technology. Instead of applying for
dynamic domain name, mapping ports or deploying transit server, you can add NVR devices to the
app for remote management.
This function will consume the device trac when the device is online.
Procedure
Step 1 Select Main Menu > NETWORK > P2P.
Figure 5-240 P2P
Step 2 Enable the P2P function.
After you enable the P2P function and connect to the Internet, the system will collect the
information such as email address and MAC address for remote access.
User's Manual
367
