Table 5-69 Multicast parameters
Parameter Description
Enable Enable the multicast function.
IP Address
Enter the IP address that you want to use as the multicast IP.
The IP address ranges from 224.0.0.0 through 239.255.255.255.
Port Enter the port for the multicast. The port ranges from 1025 through 65000.
Step 3 Click Apply.
You can log in to the web page via multicast.
On the web login page, on the Type list, select Multicast. The web will automatically
obtain the multicast IP address and join the multicast group. Then you can view the video
through multicast function.
5.11.15 Alarm Center
You can conîš‚gure the alarm center server to receive the uploaded alarm information.
Procedure
Step 1 Select Main Menu > NETWORK > Alarm Center.
Figure 5-237 Alarm center
Step 2 Click to enable the function, and then select a protocol type.
You can select Private Protocol or HTTP.
User's Manual
363
