Dahua NVR52-4KS2 SERIES User Manual

3.3.4 NVR54-4KS2/NVR54-16P-4KS2/NVR44-4KS2/
NVR44-16P-4KS2/NVR44-4KS2/L/NVR44-16P-4KS2/L/
NVR54-24P-4KS2/NVR54-16P-4KS2E/NVR58-I/NVR58-I/L/
NVR54-I/NVR54-I/L/NVR52-I/NVR52-I/L/NVR42-I/NVR42-8P-
I/NVR44-I/NVR48-I/NVR608-32-4KS2/NVR44-4KS2/I/
NVR44-16P-4KS2/I/NVR48-4KS2/I/NVR48-16P-4KS2/I/
NVR48-EI/NVR48-16P-EI/NVR44-EI/NVR44-16P-EI
Background Information
Dierent models have dierent number of HDDs.
Procedure
Step 1 Remove the xing screws on the rear panel of the device.
Figure 3-18 Remove screws
Step 2 Remove the case cover along the direction shown in the following arrow.
Figure 3-19 Remove cover
Step 3 Remove the screws on the sides of HDD bracket to take out the bracket.
●
1.5U device has one HDD bracket. For the way to remove the bracket, see Figure 3-20 .
User's Manual
98
