No. Port Name Function
CTRL
Controllable 12 V power output. It is to
control the on-o alarm relay output. It can
be used to control the device alarm output.
At the same time, it can also be used as the
power input source of some devices such as
alarm detector.
The two ports
serve as
another group
of alarm
output ports.
+12 V power output port. It can provide
power to some peripheral devices such as
camera and alarm device. Make sure the
power supply of peripheral device shall be
below 1 A.
6
MIC IN
Bidirectional talk input port. It is to receive analog audio
signal from devices such as microphone, sound pickup.
MIC OUT
Audio output port. It is to output analog audio signal to
devices such as sound box.
●
Bidirectional talk output.
●
Audio output on 1-window video monitor.
●
Audio output on 1-window video playback.
7 HDMI port
High denition audio and video signal output port. It
transmits uncompressed high denition video and multiple-
channel audio data to displays with HDMI port. The two
HDMI ports support 2-channel high denition HDMI output
of dierent sources.
8 USB port
USB 3.0 port. Connect to devices such as mouse, USB storage
device and USB burner.
9 Network port
10/100/1000 Mbps self-adaptive Ethernet port. Connect to
the network cable.
10 Power input port Input power of 100-240 V and 50-60 Hz.
11 GND.
2.2.26 NVR54-I/NVR54-I/L/NVR44-I Series
●
The following gure takes NVR5432-16P-I and NVR5432-16P-I/L series as examples.
●
The gures are for reference only.
User's Manual
65
