Dahua NVR52-4KS2 SERIES User Manual

No. Port Name Function
2 IR indicator Receives signals from the remote control.
2.1.12 NVR48-4KS2/I/NVR48-16P-4KS2/I/NVR54-EI/
NVR54-16P-EI/NVR54-16HP-EI/NVE54-24P-EI/NVR58-EI/
NVR58-16P-EI/NVR48-EI/NVR48-16P-EI
The gures are for reference only.
The NVR48-4KS2/I/NVR48-16P-4KS2/I series front panel is shown as below.
Figure 2-25 Front panel
The NVR54-16HP-EI//NVE54-24P-EI front panel is shown as below.
Figure 2-26 Front panel
The NVR58-EI/NVR58-16P-EI/NVR48-EI/NVR48-16P-EI front panel is shown as below.
Figure 2-27 Front panel
User's Manual
16
