Figure 5-86 Snapshot
Step 2 Select a channel to set schedule snapshot.
Step 3 Set a recording type.
Figure 5-87 Recording type
Step 4 Set snapshot period. For details, see Step 4 in "5.8.1.1 Conguring Video Recording
Schedule".
Step 5 Click Apply.
5.8.1.3 Conguring Recording Mode
Background Information
After you set schedule record or schedule snapshot, you need to enable the auto record and
snapshot function so that the system can automatically record or take snapshot.
●
Auto: The system automatically records the videos and snapshots according to the dened
schedule.
●
Manual: The system records general les for the entire day.
You need to have storage authorities to use the Manual recording mode.
Procedure
Step 1 Right-click the live page, and then select Main Menu > STORAGE > Record.
User's Manual
209
