Figure 2-62 Rear panel
The NVR54-24P-4KS2 series rear panel is shown as below.
Figure 2-63 Rear panel
The NVR54-16P-4KS2E series rear panel is shown as below.
Figure 2-64 Rear panel
The NVR58-16P-4KS2E series rear panel is shown as below.
Figure 2-65 Rear panel
Table 2-22 Rear panel description
Name
Function
Power switch Power on-o button.
User's Manual
35
