Figure 2-36
The HCVR7108H-V2 series rear panel is shown as below. See Figure 2-37.
Figure 2-37
Please refer to the following sheet for detailed information.
VGA video output port. Output
analog video signal. Can
connect to the monitor to view
ananlog video output.
Connect to USB storage device,
mouse, burning DVD-ROM and
etc.
High definition
media interface
High definition audio and video
signal output port. It transmits
uncompressed high definition
video and multiple-channel data
to the HDMI port of the display
device.
