VGA video output port. Output
analog video signal. Can connect to
the monitor to view ananlog video
output.
Connect to analog camera, video
input signal.
High Definition
Media Interface 2
High definition audio and video
signal output port. Support
multiple-window video matrix
output. Support tour function.
The XVR5832S rear panel is shown as below. See Figure 2-88.
Figure 2-88
Please refer to the following sheet for detailed information.
Audio output port. It is to output the
analog audio signal to the devices
such as the sound box.
Connect to video output devices
such as TV.
Bidirectional talk input port. It is to
receive the analog audio signal
output from the devices such as
microphone, pickup.
Audio output port. It is to output the
analog audio signal to the devices
such as the sound box.
