Daikin AVV - General Data; Model Nomenclature

www.DaikinApplied.com 3 IM 817-7
General DaTa
Model Nomenclature
U AVV 9 S10 A S 68 A B1 AL 22 G I B 1
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Category Code Item Code Option Code Designation & Description
Product Category 1 1 U Unit Ventilators
Model Type 2 2-4
AVS Floor, Face & Bypass AVV Floor, Valve Control
AVB Floor, Face & Bypass, Reheat AVR Floor, Valve Control, Reheat
Design Series 3 5 9 Design J
Motor Type
4
6
S PSC Motor, 3-Speed V EC Motor, Variable Airow
H EC Motor, 3-Speed
Nominal Capacity 7-8
07 750 CFM 13 1250 CFM
10 1000 CFM 15 1500 CFM
Voltage 5 9
A 115/60/1 D 208/60/3
C 208/60/1 H 230/60/3
G 230/60/1 K 460/60/3
J 265-277/60/1
Coil Options
6 10 U [1] 2 Row CW/HW 2 pipe V [5] 2 Row CW
Numerical codes [#] include op-
tional stainless steel drain pan.
D [2] 3 Row CW/HW 2 pipe S [6] 3 Row CW
E [3] 4 Row CW/HW 2 pipe W [7] 4 Row CW
F [4] 5 Row CW/HW 2 pipe Y [8] 5 Row CW
G [9] DX Z None
Heating Options 7 11-12
12 3 Element Low Cap. Electric Heat 68 Steam Low Cap.
13 6 Element Low Cap. Electric Heat 69 Steam High Cap.
65 1 Row HW 78 Opposite End Steam Low Cap.
66 2 Row HW 79 Opposite End Steam High Cap.
67 3 Row HW 00 None
Hand Orientation 8 13
A Same Hand LH E LH Heating/RH Cooling
B Same Hand RH F RH Heating/LH Cooling
D RH Electric Heat Only R Single Coil Left Hand
G RH Electric Heat / LH Cool S Single Coil Right Hand
Controls 9 14-15
## MicroTech
®
Controls (see control code table below)
Control Features Feature Selections
Open
Protocol
BACnet / Stand-Alone ● ● ● ●
LonMark ● ● ● ●
DCV
CO
2
Sensor ● ● ● ●
Factory-Installed
Keypad
LUI ● ● ● ●
Control Code
Economizer
Control
Basic B1 B5 B9 BD BH BL BP BT
Expanded E1 E5 E9 ED EH EL EP ET
Leading-Edge
L1 L5 L9 LD LH LL LP LT
23 Field Mounted Controls (By Others)
17 Digital Ready
Discharge 10 16-17
AL 16-5/8" Top Bar Grille
AK 21-7/8" Top Bar Grille Partial Adapter Back, Open Tunnel
AN 21-7/8" Top Bar Grille Full Adapter Back, Closed Tunnel
AP 21-7/8" Top Bar Grille Full Adapter Back, Cold Pipe Tunnel, Top Duct In
AM 21-7/8" Top Bar Grille 2" Step, Full Adapter Back, Closed Tunnel
AB 21-7/8" Top Bar Grille Full Adapter Back, Closed Pipe Tunnel w/ Solid Back
