Electric Heating
Table 42: Standard Motor Electric Heat Capacities, Amps, Wire Sizing, and Over Current Protection
Unit Type
AVS AVV
AVR
AVV AVR
AVS AVV
AVR
AVV AVR
AVS AVV
AVR
AVV AVR
AVS AVV
AVR
AVV AVR
Number of Electric Elements 3 6 3 6 3 6 3 6
KW 6 12 8 16 10 20 12 24
MBH 20.48 40.96 27.30 54.61 34.13 68.26 40.96 81.91
Final Air Temp F (70 F entering air temp) 95.20 120.30 95.20 120.30 95.20 120.30 95.20 120.30
Air Temperature Rise 25.20 50.30 25.20 50.30 25.20 50.30 25.20 50.30
208-60-1
Electric Heating Amperes 28.80 57.70 38.50 76.90 48.10 96.20 57.70 115.40
Unit Minimum Circuit Ampacity 39.10 75.23 51.23 99.23 63.23 123.35 75.23 147.35
Maximum Fuse Size or Circuit Breaker Amps 40 80 55 100 70 130 80 150
230-60-1
Electric Heating Amperes 25.04 50.09 33.18 66.37 41.63 83.27 50.09 100.17
Unit Minimum Circuit Ampacity 34.40 65.71 44.58 86.06 55.14 107.19 65.71 128.32
Maximum Fuse Size or Circuit Breaker Amps 35 70 45 90 60 110 70 130
265-60-1
Electric Heating Amperes 21.74 43.59 28.85 57.70 36.17 72.33 43.59 87.07
Unit Minimum Circuit Ampacity 30.28 57.59 39.16 75.22 48.31 93.52 57.59 111.94
Maximum Fuse Size or Circuit Breaker Amps 35 60 40 80 50 100 60 120
208-60-3
Electric Heating Amperes 16.70 33.30 22.20 44.40 27.80 55.50 33.30 66.60
Unit Minimum Circuit Ampacity 23.98 44.73 30.85 58.60 37.85 72.48 44.73 86.35
Maximum Fuse Size or Circuit Breaker Amps 25 45 35 60 40 80 45 90
230-60-3
Electric Heating Amperes 14.50 28.90 19.20 38.30 24.00 48.10 28.90 57.81
Unit Minimum Circuit Ampacity 21.23 39.23 27.10 50.97 33.10 63.23 39.23 75.36
Maximum Fuse Size or Circuit Breaker Amps 25 40 30 55 35 70 40 80
460-60-3
Electric Heating Amperes 7.20 14.50 9.60 19.20 12.00 24.00 14.50 28.90
Unit Minimum Circuit Ampacity 12.10 21.23 15.10 27.10 18.10 33.10 21.23 39.23
Maximum Fuse Size or Circuit Breaker Amps 15 25 20 30 20 35 25 40
Notes: 1. Unit wire sizing should be determined in accordance with NEC and local codes.
2. Amps at unit voltage, 60Hz, single phase
3. External static pressure ranges must be strictly adhered to.
