Daikin AVV - Finned Radiation System

IM 817-7 70 www.DaikinApplied.com
Table 47: 1″ (25mm) End Panel Dimensions – Non-
Standard 28″ Deep Floor Unit Ventilators 6″ (152mm) End
Panel Dimensions – Floor Unit Ventilators
All Dimensions
in Inches
16
5
/8" (422mm)
Deep
End Panels
21
7
/8" (556mm) Deep
End Panels
Top View
16
5
/
8
"
(422mm)
6"
(152mm)
21
7
/
8
"
(556mm)
6"
(152mm)
End View
With No
Cut-out
27
7
/ 8"
(708mm)
27
7
/ 8"
(708mm)
Table 48: 6″ (152mm) End Panel Dimensions – 28″ Non-
Standard Floor Unit Ventilators
All Dimensions
in Inches
21
7
/8" (556mm) Deep
End Panels
Top View
28"
(711mm)
6"
(152mm)
End View
With No
Cut-out
27
7
/ 8"
(708mm)
Finned Radiation System
Finned radiation down-draft control is available for
those who prefer it. Made of furniture-quality steel and
designed to complement the unit ventilator styling, it
is particularly appropriate for a building with very large
expanses of window where the DraftStop system is not
used, and for use in other parts of the building.
Figure 129: Typical Finned Radiation Piping
Control – Hydronic Radiation
Auxiliary Radiation
Auxiliary Radiation
Unit Ventilator
Coil
Unit Ventilator Control Valve*
(controlled by MicroTech)
Radiation Control Valve
(controlled by MicroTech)
*Not required with Face & Bypass control
