Electric Heat Wiring Diagram – Typical
Figure 123: 460 Volt, 60 Hz, 3 Phase
CAUTION
Refer to unit wiring diagram located on the right front panel, for
actual wiring. Improper wiring can cause equipment and property
damage.
