IM 817-7 66 www.DaikinApplied.com
Table 43: High Static Applications Electric Heat Capacities, Amps, Wire Sizing, and Over Current Protection
Unit Type
AVS AVV
AVR
AVV AVR
AVS AVV
AVR
AVV AVR
AVS AVV
AVR
AVV AVR
AVS AVV
AVR
AVV AVR
Number of Electric Elements 3 6 3 6 3 6 3 6
KW 6 12 8 16 10 20 12 24
MBH 20.48 40.96 27.30 54.61 34.13 68.26 40.96 81.91
Final Air Temp F (70 F entering air temp) 95.20 120.30 95.20 120.30 95.20 120.30 95.20 120.30
Air Temperature Rise 25.20 50.30 25.20 50.30 25.20 50.30 25.20 50.30
208-60-1
Electric Heating Amperes 28.80 57.70 38.50 76.90 48.10 96.20 57.70 115.40
Unit Minimum Circuit Ampacity 42.20 78.33 54.33 102.33 66.33 126.45 78.33 150.45
Maximum Fuse Size or Circuit Breaker Amps 45 80 55 110 70 130 80 175
230-60-1
Electric Heating Amperes 25.04 50.09 33.18 66.37 41.63 83.27 50.09 100.17
Unit Minimum Circuit Ampacity 37.50 68.81 47.68 89.16 58.24 110.29 68.81 131.42
Maximum Fuse Size or Circuit Breaker Amps 40 70 50 90 60 120 70 140
265-60-1
Electric Heating Amperes 21.74 43.59 28.85 57.70 36.17 72.33 43.59 87.07
Unit Minimum Circuit Ampacity 33.38 60.69 42.26 78.32 51.41 96.62 60.69 115.04
Maximum Fuse Size or Circuit Breaker Amps 35 70 45 80 55 100 70 120
208-60-3
Electric Heating Amperes 16.70 33.30 22.20 44.40 27.80 55.50 33.30 66.60
Unit Minimum Circuit Ampacity 27.08 47.83 33.95 61.70 40.95 75.58 47.83 89.45
Maximum Fuse Size or Circuit Breaker Amps 30 50 35 70 45 80 50 90
230-60-3
Electric Heating Amperes 14.50 28.90 19.20 38.30 24.00 48.10 28.90 57.81
Unit Minimum Circuit Ampacity 24.33 42.33 30.20 54.07 36.20 66.33 42.33 78.46
Maximum Fuse Size or Circuit Breaker Amps 25 45 35 55 40 70 45 80
460-60-3
Electric Heating Amperes 7.20 14.50 9.60 19.20 12.00 24.00 14.50 28.90
Unit Minimum Circuit Ampacity 15.20 24.33 18.20 30.20 21.20 36.20 24.33 42.33
Maximum Fuse Size or Circuit Breaker Amps 20 25 20 35 25 40 25 45
Note: Electric heat disconnect provided.Cabinets
