Installation Manual 3P291714-7H
DCM601B51 intelligent Touch Manager
45English
6 Quick Operation Guide
This chapter describes how to start/stop the areas and management points registered
with the intelligent Touch Manager and display their information quickly. For detailed oper-
ation procedures, refer to the user’s manual.
6.1 Viewing target area and management point information in
list format
(1)
(2)
(1) Touch the List button.
(2) The screen changes to the list view, where the name, operation mode, set tempera-
ture, and fan speed of all areas and indoor units are listed.
6.2 Viewing target areas and management points
(2)
(1) You can check the hierarchy level of the current area or indoor unit.
(2) Touch the Down button to go to the area being selected and view the areas and
management points in it.
(3)
(3) Touch the Up button to go to the area one level above the current area.
To Next Page
