dallmeier DLS 4 User Manual

DLS 4 / DLS 8 / 8 PLUS / DLS 16 / 16 PLUS
28
Dallmeier electronic
If there is no split window marked the top left split window will auto-
matically be used for toggling between the cameras.
6.3.3 Presets
The current camera - split window assignment can be saved as
preset for multi split types. 5 presets can be saved for each multi
split type.
Ø Right-click on the button of the current multi split type.
The context menu of the button will be displayed.
Fig. 6-6: Context menu for saving a preset
Ø Select Save/Preset X.
The virtual keyboard will be displayed.
Ø Enter a name for the preset.
Ø Conrm with OK.
Ø Select the corresponding preset name in the context menu to
display the saved preset.
Fig. 6-7: Context menu for selecting a preset
