DLS 4 / DLS 8 / 8 PLUS / DLS 16 / 16 PLUS
70
Dallmeier electronic
Ø Click on New.
The virtual keyboard will be displayed.
Ø Enter a name for the reference image set.
The reference image set will be created and displayed with date
and time in the Memory Selection eld.
The saved images of the cameras connected at this time are dis-
played in the Preview eld.
Fig.11-3: Reference Image Memory
If you want to create more reference image sets, please proceed
as described above.
NOTE
The storage capacity of the reference image me-
mory is limited to 1000 images. This corresponds
to approx. 41 image sets with 24 connected ca-
meras.
11.2 Comparison of reference to live image
Open the Reference Image Memory dialog for comparison of a
reference image set to current images of a connected camera.
