dallmeier DLS 4 User Manual

DLS 4 / DLS 8 / 8 PLUS / DLS 16 / 16 PLUS
33
Dallmeier electronic
The functions 6 - 8 allow to change the internal conguration of
a Dallmeier electronic UTC camera. Normally, it is not necessary
to change this conguration. This functionality is described in the
documentation Installation and Conguration.
6.5.2 Zoom control
Ø Dene the size of the relevant image section with Zoom + and
Zoom –.
A red frame in the preview window shows the position of the image
section.
Ø The control buttons allow you to position the image section.
The drag & drop method also allows you to change the position of
the section in the preview window.
6.5.3 PTZ presets
The current position of the relevant image section can be saved as
preset. For this purpose 8 presets are available.
Save as preset
Ø Direct the camera at the relevant position/scene.
Ø Right-click on the button of a PTZ preset.
The context menu of the button will be displayed.
Fig. 6-14: Context menu PTZ preset/save position
Ø Select Save position.
