dallmeier DLS 4 User Manual

DLS 4 / DLS 8 / 8 PLUS / DLS 16 / 16 PLUS
35
Dallmeier electronic
Ø Set Brightness, Contrast and Saturation.
Ø Control the images displayed in the splits.
Ø If necessary click Default to reset the settings.
Ø Finally close the panel with a click on the VGA button.
The settings will be saved automatically. They will be valid after a
reboot as well.
6.7 Audio settings
Volume and signal level of a PRemote audio connection (intercom/
Voice Talk) can be adjusted with the graphical user interface.
Please note that these settings will only affect the intercom. The
audio settings for recording remain unchanged.
Ø Click the VGA/Audio settings button.
Ø Select the Audio tab.
Fig. 6-16
Ø Set the local speaker’s Volume.
Ø Set the volume of the output signal with Level OUT.
Ø Set the volume of the received signal with Level IN.
Ø Set the volume of the local microphone output (speaker) with
Micro.
Ø Check the settings.
Ø Finally close the panel with a click on the VGA/Audio settings
button.
The settings will be saved automatically. They will be valid after a
reboot as well.
