dallmeier DLS 4 User Manual

DLS 4 / DLS 8 / 8 PLUS / DLS 16 / 16 PLUS
34
Dallmeier electronic
Position name
Ø Right-click on the button of a PTZ preset.
The context menu of the button will be displayed.
Ø Select Change name.
The virtual keyboard will be displayed.
Ø Enter a name for the PTZ preset.
Ø Conrm with OK.
Displaying a PTZ preset
Ø Click on the corresponding button to activate a saved PTZ pre-
set.
6.5.4 Leaving the UTC Zoom control
Ø Click again on the camera control button to leave the UTC
Zoom control.
6.6 VGA Settings
Brightness, contrast and saturation of the images displayed in the
splits can be set for playback and live mode.
Please note that these changes will not affect the graphical user inter-
face. The image display on a CVBS monitor or on an external evalua-
tion device / software also will not be affected.
Ø Click the VGA button.
Fig. 6-15
