DLS 4 / DLS 8 / 8 PLUS / DLS 16 / 16 PLUS
51
Dallmeier electronic
Changing the size
If you position the cursor at the edge of a marking, you can
change its size.
Deleting the marking
In order to delete a marking, just click with the right mouse but-
ton.
B) Setting the time range
The date and time elds next to Start and Stop are used to set
the time frames (time window) for the search. The procedure is
identical to the description in the Advanced search section.
C) Starting a search
Ø Click the Search button to start the search process.
The results of the search (hits) are displayed in an event list
(see Fig. 8-9).
The display Hit x/y shows the number of hits found under y and
the number of the hit currently selected under x (see Step D).
D) Viewing the results
In order to view a recognized result, click the corresponding
entry in the event list.
You can use the arrow buttons between Cancel and Set to jump
one event forward or back.
Fig. 8-9
