Assembly
Opening
1. Release one of the two snap catches on the side of the unit.
2. Pull off the cover.
Closing
Push the cover into place so that the two snap catches click shut.
Installation
Position
The unit should be positioned as follows:
• At eye level
• Not in direct sunlight
• Nowhere strong light can cause reections on the display
• Not in extreme temperatures or anywhere damp
• Not close to sources of electrical interference
The unit is secured with 3 screws.
The top one is positioned at eye level. Make sure that the head of
the screw is not sticking out so much that it is touching the PCB.
Then hook the unit on the screw and fit the two remaining screws.
