16-40 Logging Buffer Full
Option: Function:
[0]
*
No
[1] Yes View whether the logging buffer is full (see par. 15-1*). The
logging buffer will never be full when par. 15-13
Logging
Mode
is set to
Log always
[0].
2.17.5. 16-5* Ref. & Feedb.
Parameters for reporting the reference and feedback input.
16-50 External Reference
Range: Function:
0.0
*
[-200.0 - 200.0] View the total reference, the sum of digital, analog, preset, bus
and freeze references, plus catch-up and slow-down.
16-51 Pulse Reference
Range: Function:
0.0
*
[-200 - 200] View the reference value from programmed digital input(s). The
read-out can also reflect the impulses from an incremental en-
coder.
16-52 Feedback [Unit]
Range: Function:
0.0
*
[-999999.999 -
999999.999]
View the feedback unit resulting from the selection of unit and
scaling in par. 3-00, 3-01, 3-02 and 3-03.
16-53 Digi Pot Reference
Range: Function:
0.0
*
[-200 - 200] View the contribution of the Digital Potentiometer to the actual
reference.
2.17.6. 16-6* Inputs and Outputs
Parameters for reporting the digital and analog IO ports.
16-60 Digital Input
Range: Function:
0
*
[0 - 63] View the signal states from the active digital inputs. Example:
Input 18 corresponds to bit no. 5, ‘0’ = no signal, ‘1’ = connected
signal.
2. How to Programme FC 300 Programming Guide
194
MG.33.M2.02 - VLT
®
is a registered Danfoss trademark
