FC 300 CANopen
56 MG.33.J1.02 VER. 050301 – VLT is a registered Danfoss trademark
The effect of control mode upon the function of par. 8-53 Start select and 8-54 Reversing select:
If Digital input [0] is selected, the terminals
will control the start and reversing functions
Par. 8-53/54 setting: Digital input [0]
Terminal Bit 06/15 Function
0 0 Stop/Anti-clockwise
0 1 Stop/Anti-clockwise
1 0 Start/Clockwise
1 1 Start/Clockwise
If Bus [1] is selected, commands will be
activated only when given via the control word.
Par. 8-53/54 setting: Bus [1]
Terminal Bit 02/03/04 Function
0 0 Stop/Anti-clockwise
0 1 Start/Clockwise
1 0 Stop/Anti-clockwise
1 1 Start/Clockwise
If Logic AND [2] is selected, both signals must
be activated to perform the function.
Par. 8-53/54 setting: Logic AND [2]
Terminal Bit 02/03/04 Function
0 0 Stop/Anti-clockwise
0 1 Stop/Anti-clockwise
1 0 Stop/Anti-clockwise
1 1 Start/Clockwise
If Logic OR [3] is selected, activation of one signal
will activate the function.
Par. 8-53/54 setting: Logic OR [3]
Terminal Bit 02/03/04 Function
0 0 Stop/Anti-clockwise
0 1 Start/Clockwise
1 0 Start/Clockwise
1 1 Start/Clockwise

Danfoss FC 300 Specifications

General

Enclosure	IP20
Approvals	cUL, UL, CE
EMC filter	Built-in
Communication Options	CANopen, PROFIBUS DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Output Voltage	0-100% of supply voltage
