Danfoss FC 300 Manual

FC 300 CANopen
- T r o u b l e s h o o t i n g -
MG.33.J1.02 VER. 050301 – VLT is a registered Danfoss trademark 57
The effect of control mode upon the function of par. 8-55 Set-up select and 8-56 Preset reference
select:
If Digital input [0] is selected, the terminals
will control the set-up and preset reference
functions.
Par. 8-55/56 setting: Digital input [0]
Terminal Bit 00/01, 13/14 Function
Msb Lsb Msb Lsb Preset ref., Set-up no.
0 0 0 0 1
0 0 0 1 1
0 0 1 0 1
0 0 1 1 1
0 1 0 0 2
0 1 0 1 2
0 1 1 0 2
0 1 1 1 2
1 0 0 0 3
1 0 0 1 3
1 0 1 0 3
1 0 1 1 3
1 1 0 0 4
1 1 0 1 4
1 1 1 0 4
1 1 1 1 4
If Bus [1] is selected, commands will be
activated only when given via the control word.
If Logic AND [2] is selected, both signals must
be activated to perform the function.
Par. 8-55/56 setting: Bus [1]
Terminal Bit 00/01, 13/14 Function
Msb Lsb Msb Lsb Preset ref., Set-up no.
0 0 0 0 1
0 0 0 1 2
0 0 1 0 3
0 0 1 1 4
0 1 0 0 1
0 1 0 1 2
0 1 1 0 3
0 1 1 1 4
1 0 0 0 1
1 0 0 1 2
1 0 1 0 3
1 0 1 1 4
1 1 0 0 1
1 1 0 1 2
1 1 1 0 3
1 1 1 1 4
Par. 8-55/56 setting: Logic AND [2]
Terminal Bit 00/01, 13/14 Function
Msb Lsb Msb Lsb Preset ref., Set-up no.
0 0 0 0 1
0 0 0 1 1
0 0 1 0 1
0 0 1 1 1
0 1 0 0 1
0 1 0 1 2
0 1 1 0 1
0 1 1 1 2
1 0 0 0 1
1 0 0 1 1
1 0 1 0 3
1 0 1 1 3
1 1 0 0 1
1 1 0 1 2
1 1 1 0 3
1 1 1 1 4

Danfoss FC 300 Specifications

General

Enclosure	IP20
Approvals	cUL, UL, CE
EMC filter	Built-in
Communication Options	CANopen, PROFIBUS DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Output Voltage	0-100% of supply voltage
