4.14.1
Soft
Start
Connections
Figure
4-95
Closed-Top
Soft
Start
Connections
Table
4-22
Closed-Top
Soft
Start
Connection
Identification
No.
Component
1
J9:SoftStart
TemperatureSensorconnector
2
J5:ThermostaticFan
Controlconnector
3
J7:DC-DCTrigger
Signalconnector
4
J1:HighVoltage
AC/DCconnector
5
J8:SCRGate
Signalconnector
6
Ground
Page
114
of
294
-
M-SV-001-EN
Rev.
H
1/23/2023
113
