1.8 Electrical Isolation
BeforeservicingtheCompressor,isolatethecompressorpowerbycompletingthefollowingsteps:

• • • DANGER! • • •
l
Thisequipmentcontainshazardousvoltagesthatcancauseseriousinjuryordeath.Onlyqualifiedandtrainedpersonnel
shouldworkonDanfossLLCequipment.
l
Alwayswearappropriately-ratedsafetyequipmentwhenworkingaroundequipmentand/orcomponentsenergizedwith
highvoltage.
l
RemovingtheMainsInputCoverwillexposethetechniciantoahighvoltagehazardofupto632VAC.EnsuretheMains
InputpoweristurnedoffandlockedoutbeforeremovingtheMainsInputCover.

1. TurnofftheMainsInputpowertothecompressor.
2. LockOut/TagOut(LOTO)themainsdisconnecttoensurenoaccidentalorunauthorizedreapplication
oftheMainsInputpowercanoccur.
NOTE
TheMainsInputfast-actingfusesareinstalledinthepowerpanelforallcompressormodelsexcepttheTTS300/TGS230.

3. RemovetheMainsCoveronly.RefertoSection4.1.1MainsInputCoveronpage52.
4. Usinganappropriately-ratedvoltagemeter,confirmtheabsenceofACvoltage.

• • • DANGER! • • •
DonottouchanycomponentswhenremovingtheMainsInputCover.

5. IfACvoltageisnotpresent,reinstalltheMainsInputcoverandwaitatleast20minutesbefore
removingeithertheMainsInputorTopSideCover.IfACvoltagestillexists,gobacktoStep2to
determinewhythecompressorvoltageisnotisolated.
6. RemovetheTopCover,takingparticularcarenottotouchANYcomponentsunderneath.Referto
Section4.1.2TopCoveronpage53.
7. Usinganappropriately-ratedvoltagemeter,checktheDCBusBarsforDCvoltagelevel.Ifthevoltageis
above30voltsdirectcurrent(VDC),waitfive(5)minutesandrecheckuntilvoltageisbelow30VDC.
RefertoFigure1-6DCBusVoltageTestPointsonpage23.

• • • CAUTION • • •
Evenatlowvoltages,cautionshouldbeusedaroundthecapacitorstoavoidquickdischargeevents,whichcanleadtoreducedreliability.


Page 22 of 294 - M-SV-001-EN Rev. H 1/23/2023
