Unit’digit：0 phase reference source#
set by
0-multi-step speed(P01.21)
1-preset frequency (P00.07)
2:AI1
3:AI2
4:AI3(IO expansion board)
5:AI4(IO expansion board)
6:HDI pulse
7:Communication
8:PID#
Ten’s digit：Combination of multiple speed#
0：Combination method#
1：Priority method
Combination method Description:
Multispeed terminal 4 Multispeed terminal 3 Multispeed terminal 2 Multispeed terminal 1
Combination method Speed reference
Ineffective Ineffective Ineffective Ineffective Multispeed 0
Ineffective Ineffective Ineffective effective Multispeed 1
Ineffective Ineffective effective Ineffective Multispeed 2
Ineffective Ineffective effective effective Multispeed 3
Ineffective effective Ineffective Ineffective Multispeed 4
Ineffective effective Ineffective effective Multispeed 5
Ineffective effective effective Ineffective Multispeed 6
Ineffective effective effective effective Multispeed 7
effective Ineffective Ineffective Ineffective Multispeed 8
effective Ineffective Ineffective effective Multispeed 9
effective Ineffective effective Ineffective Multispeed 10
effective Ineffective effective effective Multispeed 11
effective effective Ineffective Ineffective Multispeed 12
effective effective Ineffective effective Multispeed 13
effective effective effective Ineffective Multispeed 14
effective effective effective effective Multispeed 15
Priority method Description:
Multispeed terminal 4 Multispeed terminal 3 Multispeed terminal 2 Multispeed terminal 1 Priority
method Speed reference
Ineffective Ineffective Ineffective Ineffective Multispeed 0
Ineffective Ineffective Ineffective effective Multispeed 1
Ineffective Ineffective effective random Multispeed 2
Ineffective effective random random Multispeed 3
effective random random random Multispeed 4
