Danfoss VLT AutomationDrive User Manual

Mains Supply 3 x 200 - 240V AC
FC 301/FC 302 P15K P18K P22K P30K P37K
High/ Normal Load
1)
HO NO HO NO HO NO HO NO HO NO
Typical Shaft Output [kW] 15 18.5 18.5 22 22 30 30 37 37 45
Enclosure IP20 B4 C3 C3 C4 C4
Enclosure IP21 C1 C1 C1 C1 C1
Enclosure IP55, 66 C1 C1 C1 C2 C2
Output current
Continuous
(3 x 200-240V) [A]
59.4 74.8 74.8 88 88 115 115 143 143 170
Intermittent
(60 sec overload)
(3 x 200-240V) [A]
89.1 82.3 112 96.8 132 127 173 157 215 187
Continuous
kVA (208V AC) [kVA]
21.4 26.9 26.9 31.7 31.7 41.4 41.4 51.5 51.5 61.2
Max. input current
Continuous
(3 x 200-240V) [A]
54 68 68 80 80 104 104 130 130 154
Intermittent
(60 sec overload)
(3 x 200-240V) [A]
81 74.8 102 88 120 114 156 143 195 169
Additional specifications
Max. cable size, IP20 [mm
2
(AWG)]
2)
35 (2) 90 (3/0) 90 (3/0) 120 (4/0) 120 (4/0)
Max. cable size, IP21/55/66
[mm
2
(AWG)]
2)
90 (3/0) 90 (3/0) 90 (3/0) 120 (4/0) 120 (4/0)
Max cable size with mains
disconnect [mm
2
(AWG)]
2)
35 (2) 70 (3/0) 150 (MCM 300)
Estimated power loss
at rated max. load [W]
4)
624 737 740 845 874 1140 1143 1353 1400 1636
Weight,
enclosure IP21, IP 55, 66 [kg]
45 45 45 65 65
Efficiency
4)
0.96 0.97 0.97 0.97 0.97
Mains Supply 3 x 380 - 500V AC (FC 302), 3 x 380 - 480V AC (FC 301)
PK 37 PK 55 PK75 P1K1 P1K5 P2K2 P3K0 P4K0 P5K5 P7K5
FC 301/FC 302
Typical Shaft Output [kW]
0.37 0.55 0.75 1.1 1.5 2.2 3 4 5.5 7.5
Enclosure IP20/IP21 A2 A2 A2 A2 A2 A2 A2 A2 A3 A3
Enclosure IP20 (FC 301 only) A1 A1 A1 A1 A1
Enclosure IP55, 66 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A5 A5
Output current
High overload 160% for 1 min.
Shaft output [kW] 0.37 0.55 0.75 1.1 1.5 2.2 3 4 5.5 7.5
Continuous
(3 x 380-440V) [A]
1.3 1.8 2.4 3 4.1 5.6 7.2 10 13 16
Intermittent
(3 x 380-440V) [A]
2.1 2.9 3.8 4.8 6.6 9.0 11.5 16 20.8 25.6
Continuous
(3 x 441-500V) [A]
1.2 1.6 2.1 2.7 3.4 4.8 6.3 8.2 11 14.5
Intermittent
(3 x 441-500V) [A]
1.9 2.6 3.4 4.3 5.4 7.7 10.1 13.1 17.6 23.2
Continuous kVA
(400V AC) [kVA]
0.9 1.3 1.7 2.1 2.8 3.9 5.0 6.9 9.0 11.0
Continuous kVA
(460V AC) [kVA]
0.9 1.3 1.7 2.4 2.7 3.8 5.0 6.5 8.8 11.6
Max. input current
Continuous
(3 x 380-440V) [A]
1.2 1.6 2.2 2.7 3.7 5.0 6.5 9.0 11.7 14.4
Intermittent
(3 x 380-440V) [A]
1.9 2.6 3.5 4.3 5.9 8.0 10.4 14.4 18.7 23.0
Continuous
(3 x 441-500V) [A]
1.0 1.4 1.9 2.7 3.1 4.3 5.7 7.4 9.9 13.0
Intermittent
(3 x 441-500V) [A]
1.6 2.2 3.0 4.3 5.0 6.9 9.1 11.8 15.8 20.8
Additional specifications
Max. cable size
(mains, motor, brake)
[AWG]
2)
[mm
2
]
24 - 10 AWG
0.2 - 4mm
2
24 - 10 AWG
0.2 - 4mm
2
Estimated power loss
at rated max. load [W]
4)
35 42 46 58 62 88 116 124 187 255
Weight,
enclosure IP20
4.7 4.7 4.8 4.8 4.9 4.9 4.9 4.9 6.6 6.6
Enclosure IP55, 66 13.5 13.5 13.5 13.5 13.5 13.5 13.5 13.5 14.2 14.2
Efficiency
4)
0.93 0.95 0.96 0.96 0.97 0.97 0.97 0.97 0.97 0.97
0.37 - 7.5 kW only available as 160% high overload.
Specifications
VLT
®
AutomationDrive Operating
Instructions
MG.33.AJ.02 - VLT
®
is a registered Danfoss trademark 63
10 1
0

Danfoss VLT AutomationDrive Specifications

General

Supply Voltage	3 x 200-240 V ±10% 3 x 380-500 V ±10% 3 x 525-600 V ±10%
Enclosure	IP20
Output Power Range	0.25 kW - 1.5 MW
Communication Protocols	Modbus RTU
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short circuit, Ground fault, Motor overload
Ambient Temperature Range	-10°C to +50°C (14°F to 122°F)
