Danfoss VLT AutomationDrive User Manual

10 Specifications
10.1 Power-dependent Specifications
Mains Supply 3 x 200 - 240V AC
FC 301/FC 302 PK25 PK37 PK55 PK75 P1K1 P1K5 P2K2 P3K0 P3K7
Typical Shaft Output [kW] 0.25 0.37 0.55 0.75 1.1 1.5 2.2 3 3.7
Enclosure IP20/IP21 A2 A2 A2 A2 A2 A2 A2 A3 A3
EnclosureIP 20 (FC 301 only) A1 A1 A1 A1 A1 A1 - - -
Enclosure IP55, 66 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A5 A5
Output current
Continuous
(3 x 200-240V ) [A]
1.8 2.4 3.5 4.6 6.6 7.5 10.6 12.5 16.7
Intermittent
(3 x 200-240V ) [A]
2.9 3.8 5.6 7.4 10.6 12.0 17.0 20.0 26.7
Continuous
kVA (208V AC) [kVA]
0.65 0.86 1.26 1.66 2.38 2.70 3.82 4.50 6.00
Max. input current
Continuous
(3 x 200-240V ) [A]
1.6 2.2 3.2 4.1 5.9 6.8 9.5 11.3 15.0
Intermittent
(3 x 200-240V ) [A]
2.6 3.5 5.1 6.6 9.4 10.9 15.2 18.1 24.0
Additional specifications
Max. cable size (mains, motor, brake)
[mm
2
(AWG
2)
)]
0.2 - 4 (24 - 10)
Estimated power loss
at rated max. load [W]
4)
21 29 42 54 63 82 116 155 185
Weight, enclosure IP20 [kg] 4.7 4.7 4.8 4.8 4.9 4.9 4.9 6.6 6.6
A1 (IP20) 2.7 2.7 2.7 2.7 2.7 2.7 - - -
A5 (IP55, 66) 13.5 13.5 13.5 13.5 13.5 13.5 13.5 13.5 13.5
Efficiency
4)
0.94 0.94 0.95 0.95 0.96 0.96 0.96 0.96 0.96
0.25 - 3.7kW only available as 160% high overload.
Mains Supply 3 x 200 - 240V AC
FC 301/FC 302 P5K5 P7K5 P11K
High/ Normal Load
1)
HO NO HO NO HO NO
Typical Shaft Output [kW] 5.5 7.5 7.5 11 11 15
Enclosure IP20 B3 B3 B4
Enclosure IP21 B1 B1 B2
Enclosure IP55, 66 B1 B1 B2
Output current
Continuous
(3 x 200-240V) [A]
24.2 30.8 30.8 46.2 46.2 59.4
Intermittent
(60 sec overload)
(3 x 200-240V) [A]
38.7 33.9 49.3 50.8 73.9 65.3
Continuous
kVA (208V AC) [kVA]
8.7 11.1 11.1 16.6 16.6 21.4
Max. input current
Continuous
(3 x 200-240V ) [A]
22 28 28 42 42 54
Intermittent
(60 sec overload)
(3 x 200-240V ) [A]
35.2 30.8 44.8 46.2 67.2 59.4
Additional specifications
Max. cable size [mm
2
(AWG)]
2)
16 (6) 16 (6) 35 (2)
Max cable size with mains disconnect 16 (6)
Estimated power loss
at rated max. load [W]
4)
239 310 371 514 463 602
Weight,
enclosure IP21, IP55, 66 [kg]
23 23 27
Efficiency
4)
0.964 0.959 0.964
Specifications
VLT
®
AutomationDrive Operating
Instructions
62 MG.33.AJ.02 - VLT
®
is a registered Danfoss trademark
100

Danfoss VLT AutomationDrive Specifications

General

Supply Voltage	3 x 200-240 V ±10% 3 x 380-500 V ±10% 3 x 525-600 V ±10%
Enclosure	IP20
Output Power Range	0.25 kW - 1.5 MW
Communication Protocols	Modbus RTU
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short circuit, Ground fault, Motor overload
Ambient Temperature Range	-10°C to +50°C (14°F to 122°F)
