UL Compliance
Fuses or Circuit Breakers are mandatory to comply with NEC 2009. We recommend using a selection of the following
The fuses below are suitable for use on a circuit capable of delivering 100,000 Arms (symmetrical), 240V, or 480V, or 500V, or
600V depending on the frequency converter voltage rating. With the proper fusing the drive Short Circuit Current Rating (SCCR)
is 100,000 Arms.
Recommended max. fuse
FC 300
Power
Bussmann Bussmann Bussmann Bussmann Bussmann Bussmann
[kW]
Type RK1
1)
Type J Type T Type CC Type CC Type CC
0.25-0.37 KTN-R-05 JKS-05 JJN-05 FNQ-R-5 KTK-R-5 LP-CC-5
0.55-1.1 KTN-R-10 JKS-10 JJN-10 FNQ-R-10 KTK-R-10 LP-CC-10
1.5 KTN-R-15 JKS-15 JJN-15 FNQ-R-15 KTK-R-15 LP-CC-15
2.2 KTN-R-20 JKS-20 JJN-20 FNQ-R-20 KTK-R-20 LP-CC-20
3.0 KTN-R-25 JKS-25 JJN-25 FNQ-R-25 KTK-R-25 LP-CC-25
3.7
KTN-R-30 JKS-30 JJN-30 FNQ-R-30 KTK-R-30 LP-CC-30
5.5
KTN-R-50 KS-50 JJN-50 - - -
7.5
KTN-R-60 JKS-60 JJN-60 - - -
11
KTN-R-80 JKS-80 JJN-80 - - -
15-18.5
KTN-R-125 JKS-125 JJN-125 - - -
22
KTN-R-150 JKS-150 JJN-150 - - -
30
KTN-R-200 JKS-200 JJN-200 - - -
37
KTN-R-250 JKS-250 JJN-250 - - -
Table 10.5 200-240V, Frame Sizes A, B, and C
Recommended max. fuse
FC 300
Power
SIBA Littel fuse
Ferraz-
Shawmut
Ferraz-
Shawmut
[kW] Type RK1 Type RK1 Type CC
Type RK1
3)
0.25-0.37 5017906-005 KLN-R-05 ATM-R-05 A2K-05-R
0.55-1.1 5017906-010 KLN-R-10 ATM-R-10 A2K-10-R
1.5 5017906-016 KLN-R-15 ATM-R-15 A2K-15-R
2.2 5017906-020 KLN-R-20 ATM-R-20 A2K-20-R
3.0 5017906-025 KLN-R-25 ATM-R-25 A2K-25-R
3.7
5012406-032 KLN-R-30 ATM-R-30 A2K-30-R
5.5
5014006-050 KLN-R-50 - A2K-50-R
7.5
5014006-063 KLN-R-60 - A2K-60-R
11
5014006-080 KLN-R-80 - A2K-80-R
15-18.5
2028220-125 KLN-R-125 - A2K-125-R
22
2028220-150 KLN-R-150 - A2K-150-R
30
2028220-200 KLN-R-200 - A2K-200-R
37
2028220-250 KLN-R-250 - A2K-250-R
Table 10.6 200-240V, Frame Sizes A, B, and C
