Danfoss VLT AutomationDrive User Manual

Recommended max. fuse
FC 302 SIBA Littel fuse
Ferraz-
Shawmut
Ferraz-
Shawmut
[kW] Type RK1 Type RK1 Type CC Type RK1
0.37-1.1 5017906-006 KLS-R-6 ATM-R-6 A6K-6-R
1.5-2.2 5017906-010 KLS-R-10 ATM-R-10 A6K-10-R
3 5017906-016 KLS-R-15 ATM-R-15 A6K-15-R
4 5017906-020 KLS-R-20 ATM-R-20 A6K-20-R
5.5 5017906-025 KLS-R-25 ATM-R-25 A6K-25-R
7.5 5012406-032 KLS-R-30 ATM-R-30 A6K-30-R
11 5014006-040 KLS-R-40 - A6K-40-R
15 5014006-050 KLS-R-50 - A6K-50-R
18 5014006-063 KLS-R-60 - A6K-60-R
22 2028220-100 KLS-R-80 - A6K-80-R
30 2028220-125 KLS-R-100 - A6K-100-R
37 2028220-125 KLS-R-125 - A6K-125-R
45 2028220-160 KLS-R-150 - A6K-150-R
55 2028220-200 KLS-R-200 - A6K-200-R
75 2028220-250 KLS-R-250 - A6K-250-R
Table 10.9 380-500V, Frame Sizes A, B, and C
Recommended max. fuse
FC 302 Bussmann Ferraz- Shawmut Ferraz- Shawmut Littel fuse
[kW] JFHR2 J
JFHR2
1)
JFHR2
0.37-1.1 FWH-6 HSJ-6 - -
1.5-2.2 FWH-10 HSJ-10 - -
3 FWH-15 HSJ-15 - -
4 FWH-20 HSJ-20 - -
5.5 FWH-25 HSJ-25 - -
7.5 FWH-30 HSJ-30 - -
11 FWH-40 HSJ-40 - -
15 FWH-50 HSJ-50 - -
18 FWH-60 HSJ-60 - -
22 FWH-80 HSJ-80 - -
30 FWH-100 HSJ-100 - -
37 FWH-125 HSJ-125 - -
45 FWH-150 HSJ-150 - -
55 FWH-200 HSJ-200 A50-P-225 L50-S-225
75 FWH-250 HSJ-250 A50-P-250 L50-S-250
Table 10.10 380-500V, Frame Sizes A, B, and C
1) Ferraz-Shawmut A50QS fuses may substitute for A50P fuses.
Specifications
VLT
®
AutomationDrive Operating
Instructions
82 MG.33.AJ.02 - VLT
®
is a registered Danfoss trademark
100

Danfoss VLT AutomationDrive Specifications

General

Supply Voltage	3 x 200-240 V ±10% 3 x 380-500 V ±10% 3 x 525-600 V ±10%
Enclosure	IP20
Output Power Range	0.25 kW - 1.5 MW
Communication Protocols	Modbus RTU
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short circuit, Ground fault, Motor overload
Ambient Temperature Range	-10°C to +50°C (14°F to 122°F)
