Type Description Ordering no.
Option for Slot D
MCB 107 24V DC back-up 130B1108 130B1208
External Options
Ethernet IP Ethernet master 175N2584
PC Software
MCT 10 MCT 10 set-up software - 1 user 130B1000
MCT 10 MCT 10 set-up software - 5 users 130B1001
MCT 10 MCT 10 set-up software - 10 users 130B1002
MCT 10 MCT 10 set-up software - 25 users 130B1003
MCT 10 MCT 10 set-up software - 50 users 130B1004
MCT 10 MCT 10 set-up software - 100 users 130B1005
MCT 10 MCT 10 set-up software - unlimited users 130B1006
Options can be ordered as factory built-in options, see ordering information. For information on fieldbus and application option combatibility with older
software versions, please contact your Danfoss supplier.
5.2.2 Ordering Numbers: Spare Parts
Type Description Ordering no.
Spare Parts
Control board FC 302 Coated version - 130B1109
Control board FC 301 Coated version - 130B1126
Fan A2 Fan, frame size A2 130B1009 -
Fan A3 Fan, frame size A3 130B1010 -
Fan A5 Fan, frame size A5 130B1017
Fan B1 Fan, frame size B1 external 130B1013
Fan option C 130B7534 -
Connectors FC 300 Profibus 10 pieces Profibus connectors 130B1075
Connectors FC 300 DeviceNet 10 pieces DeviceNet connectors 130B1074
Connectors FC 302 10 pole 10 pieces 10 pole spring loaded connectors 130B1073
Connectors FC 301 8 pole 10 pieces 8 pole spring loaded connectors 130B1072
Connectors FC 300 6 pole 10 pieces 6 pole spring loaded connectors 130B1071
Connectors FC 300 RS-485 10 pieces 3 pole spring loaded connectors for RS-485 130B1070
Connectors FC 300 3 pole 10 pieces 3 pole connectors for relay 01 130B1069
Connectors FC 302 3 pole 10 pieces 3 pole connectors for relay 02 130B1068
Connectors FC 300 Mains 10 pieces mains connectors IP20/21 130B1067
Connectors FC 300 Mains 10 pieces mains connctors IP 55 130B1066
Connectors FC 300 Motor 10 pieces motor connectors 130B1065
Accessory bag MCO 305 130B7535
5.2.3 Ordering Numbers: Accessory Bags
Type Description Ordering no.
Accessory Bags
Accessory bag A1 Accessory bag, frame size A1 130B1021
Accessory bag A2/A3 Accessory bag, frame size A2/A3 130B1022
Accessory bag A5 Accessory bag, frame size A5 130B1023
Accessory bag A1–A5 Accessory bag, frame size A1-A5 Brake and load sharing connector 130B0633
Accessory bag B1 Accessory bag, frame size B1 130B2060
Accessory bag B2 Accessory bag, frame size B2 130B2061
Accessory bag B3 Accessory bag, frame size B3 130B0980
Accessory bag B4 Accessory bag, frame size B4, 18.5-22 kW 130B1300
Accessory bag B4 Accessory bag, frame size B4, 30 kW 130B1301
Accessory bag C1 Accessory bag, frame size C1 130B0046
Accessory bag C2 Accessory bag, frame size C2 130B0047
Accessory bag C3 Accessory bag, frame size C3 130B0981
Accessory bag C4 Accessory bag, frame size C4, 55 kW 130B0982
Accessory bag C4 Accessory bag, frame size C4, 75 kW 130B0983
How to Order FC 300 Design Guide
100 MG.33.BD.02 - VLT
®
is a registered Danfoss trademark
